Product features:
· easy installation and maintenance, lightweight;
· the filter material has high carbon content, good adsorption effect and good air permeability, and low airflow resistance;
· it has a certain anti-corrosion effect on common solvents, weak acids, and weak bases;
· large filter area and long service life.
Product specification:
Model | Length(m) | Width(m) | Thickness(mm) | filter area(m²) | Initial resistance(Pa) | Rated airflow(m³/h) |
|
RT-HV | 305 | 610 | 292 | 2500 | ≤50 | 1700 |
RT-HV | 610 | 610 | 292 | 2500 | ≤50 | 3400 |
RT-HV | 592 | 287 | 292 | 0.65 | ≤50 | 1700 |
RT-HV | 592 | 592 | 292 | 1.2 | ≤50 | 1700 |
Note: other specifications can be customized according to requirements
Material properties
Filter material | Activated carbon filter cotton |
Initial resistance | 50Pa |
Final resistance | 250Pa |
temperature-resistant | ≤100℃ |
Temp.short peaks | ≤120℃ |
Moisture resistance (relative humidity) | ≤80%RH |
