Features:
· with high dust capacity and low resistance;
· silicone-free and resistant to chemicals such as chemical solvents and acid smog;
· long service life, multiple-use after vacuuming or cleaning, economical and practical;
· fire protection in accordance with the European standard DIN53438; In accordance with the German standard for flame retardant din5510-2, up to S4 level.
Specifications:
Model | Configuration Size | Initial resistance(Pa) | Rated air velocity(m/s) | Rated Air Flow (m³/h) |
RT-F200 | 20m * 2m * 15mm | ≤30 | 2 | >7200 |
RT-F300 | 20m * 2m * 15mm | ≤30 | 2 | >7200 |
RT-F400 | 20m * 2m * 15mm | ≤30 | 2 | >7200 |
Note: other specifications can be customized according to requirements
Technical datasheet:
Filtration class | G3(EN779)、G3(EUROVENT) |
Moisture resistance (relative humidity) | ≤99%RH |
Smoke level | SR2(DIN 5510-2) |
Average weighing efficiency | ≥85%、95%(ASHRAE52.1-1992) |
Drop grade | ST2(DIN 5510-2) |
Temp. short peaks | 120℃ |
Filter object | Coarse dust and foreign matter ≥5 μm |
Flammable level | S4(DIN 5510-2) |
Smoke density | ≤200(TB/T3237) |
Oxygen index | ≥32(TB/T3237) |
