Paint Arrestor Filter
Paint Arrestor Technical Specification
| Specifications | |
|---|---|
| Filter Type | Paint Mist Filter |
| Filter Class (EN 779) | G2, G3, G4 |
| Main Material | Fiberglass Fiber |
| Filter Object | Paint Mist, Oil Mist, Dust Particles |
| Flammability Rating | Glass 3/B1(GB/T17591-2006) |
| Dust Holding Capacity | 95%-99.8% |
| Color | Green, Blue, Yellow, Pink, Red, and White |
| Temperature Resistance | 250℃ |
| Temperature Short Peak | 300℃ |
| Humidity | 100% |
| Final Resistance | 200Pa(suggestion) |
Dimensions & Technical Details
| Model | Common Size | Weight (g/m²) | Dust Holding Capacity (g/m²) | Rated Air Flow (m³/h) | Air Velocity (m/s) | Capture Rate |
|---|---|---|---|---|---|---|
| PA-30 | 20m × (0.8/1/2)m × (25-35)mm | 180 | >3500 | 7200 | 2 | 85% |
| PA-50 | 20m × (0.8/1/2)m × (25-35)mm | 210 | >3800 | 7200 | 2 | 90% |
| PA-60 | 20m × (0.8/1/2)m × (25-35)mm | 220 | >4000 | 7200 | 2 | 90% |
| PA-75 | 20m × (0.8/1/2)m × (25-35)mm | 250 | >4300 | 6300 | 1.75 | 95% |
| PA-100 | 20m × (0.8/1/2)m × (25-35)mm | 350 | >5000 | 4500 | 1.5 | 98% |
Note: other specifications can be customized according to requirements
Features
- Extra-long service life
- Fiberglass media
- High burst resistance
- Large surface area
- Fits all commonly used filter frames
- High efficiencies at low pressure drop
Application
- Paint Booth in the Automotive Industry
- Power Plants
- Spray Booth
Paint Arrestor Filter Introduction
What is Paint Arrestor？
Fiberglass filters, commonly known as paint stop filtersorfloor filters, are designed to capture paint overspray and maintain a clean working environment. These filters are constructed from long fiberglass fibers arranged in a non-woven pattern, featuring a progressive density structure.
The air inlet side is typically green and has a fluffy texture, while the outlet side is white and denser. This design enhances the filter's ability to capture and contain paint mist effectively. The fluffy structure of the fiberglass material provides good elasticity, allowing the filter to maintain its shape without deformation, even under pressure during transportation, thereby saving space. Fiberglass filters are available in various sizes and configurations to suit different spray booth designs.
How can we be TOP supplier for paint booth filters?
As a leading supplier in spray booth filtration, RT core strengths lie in large-scale production, deep customization, and robust independent R&D capabilities. With 15 dedicated production lines, we ensure efficient and stable output, shipping over 30 containers monthly.
Simultaneously, we offer comprehensive customization services—from company logos and product specifications to packaging—tailored to client needs, helping enhance brand competitiveness. More importantly, our deep technological foundation is supported by the China Institute of Glass Fiber and backed by an independent R&D team.
Our products have undergone over five major iterations and upgrades, maintaining continuous leadership in quality and process innovation. This enables us to deliver technologically advanced, reliable, and comprehensive solutions to our customers.
Factory Display of Fiberglass Filter
Common Question of Fiberlgass Filter
How to choose quality fiberglass filter (click for article)
Lack of resilience, Fiber debris and flying, Fiber delamination and delamination, insufficient weight problem, Formaldehyde odor
Is Your Fiberglass Filter Working Effectively? (click for article)
Airflow Inspection, Visible Contaminant Build-up, Efficiency Testing, Production Quality
OUR HAPPY CLIENT FROM 98+ COUNTRIES
QUESTIONS AND ANSWERS
Q1： Can You Cut Flat Before Rolling Up On The Paint Stop Filters?
A1： Most Of The Paint Stop Filters On The Market Are Cut Flat After Rolling Up Because It Is Very Easy Operate, There Will Be A Problem That The Edge Is Not Flat. Certainly, We Can Cut Flat Before Rolling Up, Which Can Be Up To 2.6m Wide.
Q2： How Did You Pack HEPA Filter?
A2： One Unit Is Packed With PE Bag Put In 5-layer Carton. If The Customer Is Worried About The Transportation Process, We Can According To The Requirements Of The Form Of Beating Bracket + Corner Protection + Wrapping Film Packing.
Q3： Have HEPA Filter Passed The DOP/PAO Leak Test?
A3： Sure, Our HEPA Filter Is 100% Able To Pass The PAO Test. Because We Will Do An Integrity Test Of Each HEPA Filter For Efficiency And Leakage Before Shipment And Provide A Corresponding Test Report. Any Leakage Will Be Regarded As Unqualified Products And Reworked. We Are Using MPPS Scan Test For HEPA Filter Integrity Test Which According To EN 1822 Standard.
The Scanning Tracks Will Cover The Area:
Inside Filter Material, Sealant, Filter Frame, Corners, Gasket, Seal Of The Filter Mounting Assembly, The Sealant Between Filter Frame And The Gasket
Q4： How Long Does It Usually Take For Me To Receive The Goods?
A4： Depends On Whether You Want To Do Customization Your Air Filters Or Not, And Depends On The Speed Of Customs Clearance And Logistics, But We Can Guarantee To Ship Regular Air Filter In Less Than 7-10 Business Days, And We Have Customers In Singapore Who Received The Goods In Less Than 2 Weeks After We Ship Out.
Q5： What Is The Standard And Certification Of Your Products?
A5： We Implement Our Production Process In Strict Accordance With The Standards Of EN779 And EN1822.
Q6： What Is The Main Material You Are Using For HEPA Filter?
A6： We Usually Use Mircofine Glassfiber Paper, But We Also Can Do Synthetic Type Nano Paper Or PTFE Paper Type.
